Order(MOQ) :
1Payment :
50% Advance Payment , Balance Before DeliveryProduct Origin :
Bozhou City, Anhui Province ,ChinaColor :
CustomizableShipping Port :
Shanghai Or Qingdao, ChinaLead Time :
20-30 days after we receive 50% advance payment
Product Parameters
| Overall Dimensions | 9780mm*2496mm*3990mm(L*W*H) |
| Tare Weight | 13950kg |
| Payload | 35000kg |
| Front Overhang | 1500mm |
| Rear Overhang | 2880mm |
| Wheelbase | 4000mm+1400mm |
| Track (F/R) | 2022mm/1830mm |
| Chassis Brand | SINOTRUK HOWO |
| Chassis Model | ZZ1257N4048W, driving type 6x4 |
| Cab | HW76, left hand drive, air-conditioner, one sleeper |
| Engine | SINOTRUK WD615.47, 371hp(273KW), Euro II emission standard, 4-stroke direct injection diesel engine, 6-cylinder in-line with water cooling, turbo-charging and inter-cooling, displacement 9.726L |
| Transmission | HW19710, No. of speeds: 10 forward 2 reverse |
| Steering | German ZF8098, turning system pressure 18MPa |
| Rear Axle | HC16 tandem axle, rated load 2x13ton, ratio 5.73 |
| Wheels and tires | Rim 9.0-22.5; tire 12R22.5, 10 units; Spare wheel carrier: with one spare wheel |
| Brakes | Service brake: Dual circuit pneumatic brake; Parking brake: Spring energy, compressed air operating on rear wheels; Auxiliary brake: Engine exhaust brake |
Cement Mixing Semi Trailer
12 m3 Concrete mixing Semi Trailer
The generation product truly realizes the multi-purpose function of the loading function, the stirring function, the transportation function, and the car washing, they provide excellent maneuverability.
Read More
This product is an on-site construction vehicle that combines the functions of concrete batch processing equipment, transportation and concrete mixing station. It is currently the most popular mixing tanker product. Owning it will greatly improve your work efficiency.
Read More
Economical and practical, with convenient operation ,uniform mixing and stable performance. It is suitable for bridge,tunnel,highway and urban&rural construction.
Read More
This product is an on-site construction vehicle that combines the functions of concrete batch processing equipment, transportation and concrete mixing station. It is currently the most popular mixing tanker product. Owning it will greatly improve your work efficiency.
Read More
Concrete Mixer Trucks are mainly used for mixing and carrying concrete in long distance. Then can delay concrete primary concretion, avoid concrete stratification and separation, ensure the concrete can be normal at work site. Our concrete truck mixers adopt European modern style, attractive appearance, rational structure and stable performance. We can match upper mixer with different chassis truck according to customers' request, such as Dongfeng, Sinotruk, Shaman, Auamn, FAW, JAC, Hongyan, Beiben, Dayun, Hino, Misubishi, etc.
Read More
The mixer size is suitable for limited place and widely used in new rural construction, urban construction, tunnel, airport, seaport, high-speed rail site, remote areas where there are no electric power, middle projects, farmer's houses, building, country road, irrigation, reservoir, mine, rural bridges, high-way road etc, which characterized in saving labors, high efficiency concrete output.
Read More
The mixer size is suitable for limited place and widely used in new rural construction, urban construction, tunnel, airport, seaport, high-speed rail site, remote areas where there are no electric power, middle projects, farmer's houses, building, country road, irrigation, reservoir, mine, rural bridges, high-way road etc, which characterized in saving labors, high efficiency concrete output.
Read More
The mixer size is suitable for limited place and widely used in new rural construction, urban construction, tunnel, airport, seaport, high-speed rail site, remote areas where there are no electric power, middle projects, farmer's houses, building, country road, irrigation, reservoir, mine, rural bridges, high-way road etc, which characterized in saving labors, high efficiency concrete output.
Read More
The mixer size is suitable for limited place and widely used in new rural construction, urban construction, tunnel, airport, seaport, high-speed rail site, remote areas where there are no electric power, middle projects, farmer's houses, building, country road, irrigation, reservoir, mine, rural bridges, high-way road etc, which characterized in saving labors, high efficiency concrete output.
Read More
The mixer size is suitable for limited place and widely used in new rural construction, urban construction, tunnel, airport, seaport, high-speed rail site, remote areas where there are no electric power, middle projects, farmer's houses, building, country road, irrigation, reservoir, mine, rural bridges, high-way road etc, which characterized in saving labors, high efficiency concrete output.
Read More
The mixer size is suitable for limited place and widely used in new rural construction, urban construction, tunnel, airport, seaport, high-speed rail site, remote areas where there are no electric power, middle projects, farmer's houses, building, country road, irrigation, reservoir, mine, rural bridges, high-way road etc, which characterized in saving labors, high efficiency concrete output.
